Description
Powerful. Compact pure sine wave inverter delivers clean, reliable AC power from 12V/24V batteries for sensitive electronics, appliances and tools in cars, trucks, RVs and off-grid setups.
Specifications:
- Certification: CE
- Color: Blue
- Output Waveform: Pure Sine Wave
- Peak Output Power: 2000W
- Continuous Output Power (Rated): 1000W
- Frequency: 50Hz ±2Hz / 60Hz ±2Hz
- No-load Current Draw: < 0.8 A
- Conversion Efficiency: >90%
- Input Voltage: DC 12V / 24V
- DC Voltage Range (12V): 9.0V – 15.5V
- Output AC Voltage: 220V / 110V (switchable); AC Range: 210V–240V / 110V–130V
- Low Voltage Alarm: 10.0V DC ±0.5V
- Low Voltage Shut Down: 9.0V DC ±0.5V
- Over Voltage Shut Down: 15.5V
- Overload Response: Shut off output
- Over Temperature: Automatic shut off
- Fuses / Protection: Internal fuses, short circuit protection
- Start: Soft start
- USB Output: Yes
- Socket Style: EU / Universal
- Socket Type: Universal
- Material: Aluminum alloy
- Size: 235 mm × 112 mm × 60 mm (9.25 × 4.41 × 2.36 in)
- Weight: 1.2 kg (2.65 lb)
- Safety Protections (8): Reverse polarity protection; Low input voltage protection; High input voltage protection; Over-current protection; Short circuit protection; Over temperature protection; Overload protection; Internal fuses
- Warranty: 1 Year
Package Included:
- 1 × Inverter
- 2 × Crimpers
- User Manual
Overview & Tips: Use this pure sine wave inverter to run laptops, TVs, small appliances and power tools (check wattage). For high-draw or inductive loads (fridges, pumps, drills, microwaves, hair dryers), select an inverter with higher continuous power or allow 3–7× starting capacity. Use the supplied battery cables or equivalent heavy-gauge wiring; replace with thicker cable for larger loads to ensure full power delivery. Never connect the inverter directly to household AC grid and avoid reverse polarity connections.
#PowerInverter #PureSineWave #FanzyMarket
Safety Notes:
Electrical device: follow battery and charging safety. Always connect positive (+) and negative (−) correctly and use the provided fuses and heavy-gauge cables. Do not connect the inverter to the mains/grid. Ensure good ventilation and keep the unit dry and away from flammable materials. Disconnect battery before maintenance and keep out of reach of children.
